P7200151 -------- TECHNICAL DATA --------   Power
consumption 400W Power supply voltage 100 - 245V Voltage
frequency 50/60Hz Fuse F5AL Diode type 4in1 Diode
power 30W Display Color LCD Number of diodes 12 --------
UTILITY DATA --------   Color RGBW Color rendering index
(CRI) 85 Beam angle (min) 50° Beam angle
(max) 50° Dimming Linear: 0 - 100% Flash frequency
(min) 1Hz Flash frequency (max) 20Hz Number of DMX channels 30
modes DMX standard DMX 512 Control interface 4
buttons Operating modes DMX512, Manual, Auto, Sound-controlled, Master /
Slave Features 16-bit brightness control, smooth brightness control
(selectable control characteristic curve), bulb simulation (delayed response to
brightness change) DMX signal regeneration, Electronic protection against
overheating -------- INTERFACES --------   AC
IN powerCON AC OUT powerCON DMX IN XLR - 3 pin DMX
OUT XLR - 3 pin ----- PHYSICAL CHARACTERISTICS -----   IP
Rating IP20 Housing made Aluminum +
steel Cooling Active Height [cm] 8 - (with packaging 16
cm) Width [cm] 97 - (with packaging 107 cm) Depth [cm] 19 -
(with packaging 22 cm) Weight [kg] 5,2 Weight with packaging
[kg] 6,4
